We are the authorised distributors for the entire range of Eaton- Vickers products including hydraulic pumps, motors, valves, cylinders, filters and accessories.



Pumps Motors Pressure Controls
Flow Controls Directional Controls Check Valves











Pumps

Fixed Displacement - Single Pumps

Type

Model

Displacement (cc/rev)

Max Speed (rpm)

Max Pressure
(bar)

Vane

V100

5-12

1800

160

V200

7 - 38

1800

140

V30

48 - 90

2700

175

Intra Vane

25V

40-67

2700

210

Quiet Intra Vane

25VQ

40 -67

2700

210

35VQ

81 - 121

2500

210

45VQ

138 - 193

2200

175





Fixed Displacement - Double Pumps







Type

 Model Displacement (cm3/  rev)  Max Speed (rpm) Max Pressure (bar)


Shaft-end

Cover-end


Vane V2200 7 - 38 7 - 38  1800 140
Intra Vane 2520V 40 -67 18 - 45 2700 210
Quiet Intra Vane 2520VQ 40 - 67 18 -45 2700 210
3520VQ 81 - 121 18 - 45 2500 210
4520VQ 138 - 193 18 - 45 2200 175





Variable Displacement Type



Type

Model

Displacement (cc/rev)

Max Speed (rpm)

Max Pres (bar)









Axial Piston

PVB 5 10 3600 210

PVB 10

21

3200

210

PVB 15

31

3000

140

PVQ 10

10

3600

210

PVQ 20

21

3200

210

PVQ 32

31

3000

140



Displacement Controls Options Available
Pressure Compensator, screw and locknut pressure adjustment, Maximum displacement stop control.
^Top





Motors


Type Model Displacement (cm3 / rev)  Theo. Torque (Nm/bar)  Max Speed Max Pressure (bar)

Direct vane

 M2 - 200 24 -36 0.38 - 0.57 2200 70

Intra Vane

 25 M 44 - 68 0.70 - 1.09 3000 175
  35 M 83 - 122 1.33 - 1.94 3000 175

Piston

 MFB - 10 21 0.33 3200 210
^Top





Pressure Controls



Pipe Mounted Relief Valve
Type Model Port Size (inches)  Max Flow Rate (lpm)  Max Press(bar)

Remote/direct operated

 C-175 1/4 BSP 12 210

Balanced piston type

CT - 06 3/4 BSP 75 210

Electrically Selected

 CT5 - 06 3/4 BSP 75 210





Gasket Mounted Relief Valve
Type Model Pipe Size (inches)  Max Flow Rate (lpm)  Max Pressure (bar)

Remote/direct operated

CGR-02

1/4

1.5

210

Balanced piston type

CG-06

3/4

95

210

Electrically Selected

CG5 - 06

3/4

95

210





Modular Valves
Type Model Size Max Flow Rate (lpm)  Max Pressure (bar)

Sequence, Unloading & back pressure valve

DGMR - 3

CETOP - 3

38

250

Relief Valve

DGMC - 3

CETOP - 3

38

250

Reducing Valve

DGMX - 3

CETOP - 3

38

250



All valves are available with screw and locknut pressure adjusters. Optional micrometer thimbles,
with or without keylock adjustments.

^Top





Flow Controls



Type

Model

 Size

Max Flow Rate (lpm)

Max Pressure (bar)

Non compensated pipe Mounted
FN - 03

3/8" BSP

38

210

FN - 06

3/4" BSP

76

210

FN - 10

1  1/4" BSP

189

210

Pressure & Temperature Compensated Gasket mounted
FCG - 02

1/2"

25

210

FCG - 03

3/4"

106

210

Modular

 DGMFN - 3

CETOP - 3

38

250

Sandwitch

DGFN - 01

CETOP - 5

46

210
^Top





Directional Controls





 Type Model Size Max Flow Rate (lpm)  Max Pressure (bar)

Direct Solenoid (wet armature)
DG4V - 3S
 CETOP - 3 40 350
DG4V5 CETOP - 5 120 315
Solenoid operated pilot controlled DG5S8/DG5V8 CETOP - 8 170/700 210/350
^Top





Check Valves



Type Model Port Size  Max Flow Rate (lpm)  Max Pressure (bar)
Inline DT8P1 3/8" - 1 1/4" BSP  12-190 210
Right angle Gasket mounted  C4G-815 3/4" 76 210
C5G-825 1 1/4" 450 210
Modular Direct Operated DGMDC-3 CETOP-3 38 250
Modular Pilot operated

DGMPC-3

 CETOP-3 38 250





Filters



Type Model Filtration Rating (Micron) Flow Rate (lpm)
Suction Strainer IND-STR 149  45-180
Return Line Filter OFM-100 10 or 25 189
OFM-200 10 or 25 568
